Product Introduction
Heating area:300-1800 square meters.
Effects of combustion chamber heughtening design,with long service life.
Stainless steel dust precipitator dust,simple,high effciency.
Design of insulation three return ,the heat loss is reduced to the minimum.
The high thermal effciency of 90%
The unique 20mm wall thickness of heat resistant cast steel pipe,ensure the combustion ten years without deformation.
All the indicators have reached the national classlregion environmental sandards.
Technical Parameter
| Type | Heat output | Hot air temperature | Heating walume | Consume of fuel | Power | Outer Size | Weight | Heating area |
| (kcal/h) | ℃ | (m3/h) | (kg/h) | (kw) | (mm) | (kg) | ㎡ | |
| HYMR-5 | 50000 | 80-150 | 9500 | 5-10 | 1.87 | 1250*800*1850 | 750 | 300 |
| HYMR-10 | 100000 | 80-150 | 18700 | 10-20 | 3.55 | 2030*950*2040 | 1150 | 600 |
| HYMR-20 | 200000 | 80-150 | 37400 | 30-40 | 5.15 | 2450*1250*2280 | 1700 | 1200 |
| HYMR-30 | 300000 | 80-150 | 39400 | 40-50 | 6.75 | 2720*1250*2600 | 2400 | 1800 |
| HYMR-40 | 400000 | 80-150 | 42500 | 50-60 | 9.1 | 2920*1300*2600 | 2600 | 2400 |
